QM Series Machine Vice
Performance and character
1. It is one of main attachments for milling, drilling machine, it is particularly suitable for the finishing of precision parts.
2. The accuracy of vice (Parallelism and perpendicularity ) ≦ 0.025mm/100mm.
3. The special segment in the movable jaw forces the vertical pressure downward when the horizontal pressure works, so that this jaw does not lift the workpiece.
4.These units can be ordered separately or with swivel base.
5. Four positions allow extra capacity to change opening of jaw.
