Built-in Angle Orientation Mounting Type

Description:

  • Pneumatic unlock Pneumatic automatic chip removal
  • Material: hard stainless steel
  • Surface and piston hardening treatment Repeat positioning accuracy <0.005mm

More:

FEATURES:

FEATUERS:
Pneumatic unlock
Pneumatic automatic chip removal
Unlock pressure: Q10 minimum 5.5bar- maximum 12bar
                                         Q12 minimum 4.5bar- maximum 12bar
Material: hard stainless steel
Surface and piston hardening treatment
Repeat positioning accuracy <0.005mm

Angular orientation

Application Field
The UNILOCK is designed to reduce the time it takes to change tooling. It can be used in a variety of applications such
as metal cutting and non-cutting, as well as in food, chemical and pharmaceutical industries and automation.
Model D1 D2 D3 D4 H1 H2 M T K Unlock Method Clamping force Tensioning force Blowing dust Weight
Q10 112 22 78 88 10 35 6xM6 25 8 pneumatic 10KN 25KN 1.4KG
Q20 138 32 102 115 15 49 8xM6 34 10 pneumatic 17KN 55KN 2.6KG

Built-in Angle Orientation Mounting Type
zero positions with vise
chuck
 one single zero position
